The MCS-R15 Screw is a heavy-duty linear actuator designed for controlled motion in precision automation systems. Featuring a high-load screw drive and rigid aluminum extrusion, it delivers consistent linear positioning with excellent repeatability. The actuator supports multiple motor mounting options and includes integrated cable management for streamlined setup. Built with industrial-grade components, the MCS-R15 Screw provides stable performance, low backlash, and long-term reliability in demanding environments.
Each X-Y-Z system can be supplied with T-slot sensors, gearboxes, or motor mounting adaptors upon request. All X-Y-Z systems include cable track; please refer to the Product Specification download document for the standard size. Motor sizing information is provided in the Product Specification document. For travel requirements exceeding standard values, contact Macron Dynamics for assistance.
These are standard specifications, if you need a custom configuration, please use our custom configuration request form.
| Motion | Horizontal |
| Max Speed - Horizontal[Vertical] - mm/sec | 3000[500] |
| Max Load - Vertical - lbs | 15 |
| Repeatability - mm | +/- 0.5 |
| Moment Load - in-lbs[Nm] | Contact Macron Dynamics |
| Positional Accuracy - mm/meter | 1 |
| Acceleration Max - Gs | 2 |
| Recommended Belt Running Load - lbf[N] | 100[445] |
| Cart Guide | Linear bearing with profile rail |
| System Weight - kg | See Data Sheet |
| Weight of Cart - lbs[kgs] | See Data Sheet |
| Weight of Belt - kgs based on travel selected | See Data Sheet |
| Travel per Revolution - mm | See Data Sheet |
| Pulley Pitch Diameter - mm | See Data Sheet |
| Pulley Material / Width - mm | See Data Sheet |
| Breakaway Torque - oz-in | N/A |
| Coefficient of Friction | 0.1 |
| Rolling Resistance - lbs / kgs | N/A |
| X Axis Travel - min to max | 150 to 3000 |
| Y Axis Travel - min to max | 150 to 2000 |
| Z Axis Travel - min to max | 100 to 300 |
