VERSATILE. SCALABLE. SIMPLE.
The MCS-UC3 is a compact linear actuator designed for controlled motion in industrial and laboratory automation environments. Featuring a precision lead screw drive within a lightweight aluminum housing, it delivers smooth, accurate travel over short distances. The actuator supports flexible motor mounting options for seamless integration into small-scale or space-constrained systems. Built with durable materials and low-maintenance components, the MCS-UC3 ensures reliable performance in repeatable, low-load applications.
Each X-Y-Z system can be supplied with T-slot sensors, gearboxes, or motor mounting adaptors upon request. All X-Y-Z systems include cable track; please refer to the Product Specification download document for the standard size. Motor sizing information is provided in the Product Specification download document. For travel requirements over standard values, contact Macron Dynamics for assistance.
These are standard specifications, if you need a custom configuration, please use our custom configuration request form.
| Motion | Vertical |
| Max Speed - Horizontal[Vertical] - mm/sec | 3000[2000] |
| Max Load - Vertical - lbs | 900 |
| Repeatability - mm | +/- 0.5 |
| Moment Load - in-lbs[Nm] | Contact Macron Dynamics |
| Positional Accuracy - mm/meter | 1 |
| Acceleration Max - Gs | 2 |
| Recommended Belt Running Load - lbf[N] | 1000[4448] |
| Cart Guide | Track roller with round rail |
| System Weight - kg | See Data Sheet |
| Weight of Cart - lbs[kgs] | See Data Sheet |
| Weight of Belt - kgs based on travel selected | See Data Sheet |
| Travel per Revolution - mm | See Data Sheet |
| Pulley Pitch Diameter - mm | See Data Sheet |
| Pulley Material / Width - mm | See Data Sheet |
| Breakaway Torque - oz-in | N/A |
| Coefficient of Friction | 0.2 |
| Rolling Resistance - lbs / kgs | N/A |
| X Axis Travel - min to max | 150 to 8000 |
| Y Axis Travel - min to max | 150 to 8000 |
| Z Axis Travel - min to max | 150 to 3000 |
Enter your configuration options to submit a Request for a Quote or a CAD drawing:
Macron Dynamics specializes in designing and building virtually any configuration to meet your unique automation needs. Our innovative solutions enhance efficiency, optimize workspace utilization, and prioritize worker safety—reducing injuries while maximizing productivity.
We offer custom solutions for applications requiring from one to thousands of units, and units physically much smaller and larger than our standard models.
