MGS-M6S

MGS-M6S END

MGS-M6S SIDE

MGS-M6S TOP

MGS-M6S

The MGS-M6S is a compact linear actuator designed for precision motion in light-duty industrial automation applications. Featuring a belt-driven system housed in a rigid aluminum extrusion, it delivers smooth and accurate travel across short to moderate distances. Its modular design supports various motor and gearbox mounting options, allowing for flexible integration into multi-axis configurations. Built with durable materials, the MGS-M6S provides reliable performance, minimal maintenance, and consistent operation in space-constrained environments.

XX-Y' configuration.
Connection Hardware and Torque Tube included with the Assembly.
User defined Strokes for Each Axis.
Center Drive Right Angle Reducer offered upon request.
Mounting flexibility in either horizontal, vertical, or inverted orientation.

Datasheet - MGS-M6S

View Specifications

Download CAD Model

Request Quote Connect with an Engineer

Product Notes

Each XX-Y’ system can be supplied with T-slot sensors, gearboxes, or motor mounting adaptors upon request. All XX-Y systems include cable track; please refer to the Product Specification download document for the standard size. Motor sizing information is provided in the Product Specification download document. For travel requirements over standard values, contact Macron Dynamics for assistance.

User Guides

Gearbox Installation graphic

Gearbox Install

User Guide Maintenance

EDC PDF Thumbnail

EDC Distance Coupling Installation

Videos

Accessories

Item # 397, Torque Wrench 25-250 lbs-in
