| Length – mm (ft) | 6096 (20) |
| Material | 6005 – T5 Aluminum |
| Finish | Clear Anodized (For other finishes contact Macron) |
| Ix – cm4 (in4) | 298.10 (7.162) |
| Iy – cm4 (in4) | 1030.59 (24.760) |
| Wx – cm3 (in3) | 74.53 (4.548) |
| Wy – cm3 (in3) | 128.82 (7.861) |
| Profile Section – cm2 (in2) | 40.48 (6.275) |
| Weight – kg/m (lbs/ft) | 10.93 (7.35) |
| Length – mm (ft) | 6096 (20) |
| Material | 6005 – T5 Aluminum |
| Finish | Clear Anodized (For other finishes contact Macron) |
| Ix – cm4 (in4) | 266.26 (6.397) |
| Iy – cm4 (in4) | 454.15 (10.911) |
| Wx – cm3 (in3) | 66.57 (4.062) |
| Wy – cm3 (in3) | 75.69 (4.619) |
| Profile Section – cm2 (in2) | 32.86 (5.093) |
| Weight – kg/m (lbs/ft) | 8.87 (5.96) |
| Length – mm (ft) | 6096 (20) |
| Material | 6005 – T5 Aluminum |
| Finish | Clear Anodized (For other finishes contact Macron) |
| Ix – cm4 (in4) | 517.25 (12.414) |
| Iy – cm4 (in4) | 33.13 (0.795) |
| Wx – cm3 (in3) | 64.65 (3.944) |
| Wy – cm3 (in3) | 16.56 (1.010) |
| Profile Section – cm2 (in2) | 21.48 (3.329) |
| Weight – kg/m (lbs/ft) | 5.80 (3.89) |
| Packaging – per case | 4 |
| Length – mm (ft) | 6096 (20) |
| Material | 6005 – T5 Aluminum |
| Finish | Clear Anodized (For other finishes contact Macron) |
| Ix – cm4 (in4) | 190.29 (4.567) |
| Iy – cm4 (in4) | 30.84 (0.740) |
| Wx – cm3 (in3) | 15.42 (0.941) |
| Wy – cm3 (in3) | 38.06 (2.322) |
| Profile Section – cm2 (in2) | 17.88 (2.771) |
| Weight – kg/m (lbs/ft) | 4.94 (3.31) |
| Packaging – per case | 5 |
| Length – mm (ft) | 6096 (20) |
| Material | 6005 – T5 Aluminum |
| Finish | Clear Anodized (For other finishes contact Macron) |
| Ix – cm4 (in4) | 24.02 (0.577) |
| Iy – cm4 (in4) | 220.02 (5.286) |
| Wx – cm3 (in3) | 12.01 (0.733) |
| Wy – cm3 (in3) | 36.67 (2.238) |
| Profile Section – cm2 (in2) | 18.88 (2.927) |
| Weight – kg/m (lbs/ft) | 5.10 (3.43) |
| Packaging – per case | 4 |
| Length – mm (ft) | 6096 (20) |
| Material | 6005 – T5 Aluminum |
| Finish | Clear Anodized (For other finishes contact Macron) |
| Ix – cm4 (in4) | 25.64 (0.616) |
| Iy – cm4 (in4) | 131.03 (3.148) |
| Wx – cm3 (in3) | 12.82 (0.782) |
| Wy – cm3 (in3) | 26.21 (1.599) |
| Profile Section – cm2 (in2) | 12.43 (1.927) |
| Weight – kg/m (lbs/ft) | 3.36 (2.26) |
| Packaging – per case | 4 |
| Length – mm (ft) | 6096 (20) |
| Material | 6005 – T5 Aluminum |
| Finish | Clear Anodized (For other finishes contact Macron) |
| Ix – cm4 (in4) | 247.62 (5.949) |
| Iy – cm4 (in4) | 346.34 (8.321) |
| Wx – cm3 (in3) | 61.90 (3.778) |
| Wy – cm3 (in3) | 86.58 (.002) |
| Profile Section – cm2 (in2) | 39.77 (6.164) |
| Weight – kg/m (lbs/ft) | 10.74 (7.22) |
| Length – mm (ft) | 6096 (20) |
| Material | 6005 – T5 Aluminum |
| Finish | Clear Anodized (For other finishes contact Macron) |
| Ix – cm4 (in4) | 186.89 (4.49) |
| Wx – cm3 (in3) | 46.72 (2.851) |
| Profile Section – cm2 (in2) | 206.35 (4.085) |
| Weight – kg/m (lbs/ft) | 7.11 (4.78) |
| Packaging – per case | 4 |
| Length – mm (ft) | 6096 (20) |
| Material | 6005 – T5 Aluminum |
| Finish | Clear Anodized (For other finishes contact Macron) |
| Ix – cm4 (in4) | 127.72 (3.068) |
| Wx – cm3 (in3) | 31.93 (1.948) |
| Profile Section – cm2 (in2) | 20.27 (3.142) |
| Weight – kg/m (lbs/ft) | 5.28 (3.547) |
| Packaging – per case | 4 |
| Length – mm (ft) | 6096 (20) |
| Material | 6005 – T5 Aluminum |
| Finish | Clear Anodized (For other finishes contact Macron) |
| Ix – cm4 (in4) | 101.88 (2.451) |
| Iy – cm4 (in4) | 26.85 (.643) |
| Wx – cm3 (in3) | 25.34 (1.56) |
| Wy – cm3 (in3) | 13.41 (.816) |
| Profile Section – cm2 (in2) | 16.64 (2.45) |
| Weight – kg/m (lbs/ft) | 4.55 (3.08) |
| Packaging – per case | 8 |
| Length – mm (ft) | 6096 (20) |
| Material | 6005 – T5 Aluminum |
| Finish | Clear Anodized (For other finishes contact Macron) |
| Ix – cm4 (in4) | 67.22 (1.615) |
| Iy – cm4 (in4) | 17.64 (.424) |
| Wx – cm3 (in3) | 16.80 (1.025) |
| Wy – cm3 (in3) | 8.93 (.545) |
| Profile Section – cm2 (in2) | 11.56 (1.792) |
| Weight – kg/m (lbs/ft) | 3.10 (2.08) |
| Packaging – per case | 8 |
| Length – mm (ft) | 6096 (20) |
| Material | 6005 – T5 Aluminum |
| Finish | Clear Anodized (For other finishes contact Macron) |
| Ix – cm4 (in4) | 14.18 (..340) |
| Wx – cm3 (in3) | 7.09 (.433) |
| Profile Section – cm2 (in2) | 9.22 (1.43) |
| Weight – kg/m (lbs/ft) | 2.53 (1.69) |
| Packaging – per case | 16 |
| Length – mm (ft) | 6096 (20) |
| Material | 6005 – T5 Aluminum |
| Finish | Clear Anodized (For other finishes contact Macron) |
| Ix – cm4 (in4) | 9.62 (.231) |
| Wx – cm3 (in3) | 4.81 (.294) |
| Profile Section – cm2 (in2) | 6.48 (1.004) |
| Weight – kg/m (lbs/ft) | 1.78 (1.192) |
| Packaging – per case | 16 |
| Length – mm (ft) | 6096 (20) |
| Material | 6005 – T5 Aluminum |
| Finish | Clear Anodized (For other finishes contact Macron) |
| Ix – cm4 (in4) | 16.52 (.397) |
| Iy – cm4 (in4) | 4.68 (.112) |
| Wx – cm3 (in3) | 5.90 (.360) |
| Wy – cm3 (in3) | 3.34 (.204) |
| Profile Section – cm2 (in2) | 5.65 (.876) |
| Weight – kg/m (lbs/ft) | 1.56 (1.05) |
| Length – mm (ft) | 6096 (20) |
| Material | 6005 – T5 Aluminum |
| Finish | Clear Anodized (For other finishes contact Macron) |
| Ix – cm4 (in4) | 2.39 (.057) |
| Wx – cm3 (in3) | 1.71 (.105) |
| Profile Section – cm2 (in2) | 2.99 (.46) |
| Weight – kg/m (lbs/ft) | 0.83 (.55) |
Macron Dynamics specializes in designing and building virtually any configuration to meet your unique automation needs. Our innovative solutions enhance efficiency, optimize workspace utilization, and prioritize worker safety—reducing injuries while maximizing productivity.
We offer custom solutions for applications requiring from one to thousands of units, and units physically much smaller and larger than our standard models.
