Specifications
| Specifications | |
| Motion | Horizontal or Vertical |
| Maximum Speed | 10160 mm/sec |
| Maximum Load | 1000 lbs. |
| Repeatability | +/- 0.025 mm |
| Acceleration Exceeding | 20 G's |
| Beam Dimensions | 80 x 98 mm |
| Motor Sizing Information | |
| Weight of Drive Pulley | 28.4 oz. |
| Weight of Idler Pulley | 26.4 oz. |
| Weight of Belt | 0.95 lbs. (372 mm), 1.34 lbs. (672 mm), 1.59 lbs. (872 mm), 1.91 lbs. (1122 mm), 2.23 lbs. (1372 mm), 2.62 lbs. (1672 mm), 2.87 lbs. (1872 mm) |
| Travel per Revolution | 150 mm |
| Pulley Pitch Diameter | 47.74 mm |
| Pulley Material / Width | steel / 50 mm |
| Weight | |
| First meter of travel | 28 lbs. |
| Additional per meter | 11 lbs. |
| Travels | |
| Standard Travels | 372 to 1872 mm |
Features
- Extruded aluminum actuator body with T-slots for ease of mounting
- Easy to adjust belt tensioner
- One piece, machined and stress proof shafted pulley
- Zero backlash belt to pulley design
- Corrosion resistant components
